TILT®

Toilet Incline Lift

The TILT® Toilet Incline Lift from EZ-ACCESS is a patented toileting aid that lifts to your natural body movement, providing the independence needed to maintain dignity in the bathroom. By combining the functionality of a heavy duty commode and a lift chair, the lightweight and durable TILT offers an easy-to-use bathroom safety solution. It also features handheld control to make the lifting process convenient for the user or caregiver. Designed for quick, simple installation. Available in battery or corded power.

Locate a dealer
Locate a dealer
Built in the USA
2-Year
Warranty
EASY INSTALLATION

This lightweight unit, weighing just 34 pounds, can be installed in as little as 15 minutes.


AVAILABLE IN CORDED OR CORDLESS POWER

The corded power unit plugs into a standard GFCI outlet. The cordless power unit features a rechargeable battery pack that mounts to the wall (5” x 16” wall space required) within 3’ of the TILT and provides power for approximately 20 cycles with a full charge.

HAND GRIPS

Handles feature non-slip covers, allowing you to maintain a secure grip while the seat raises and lowers.

COMPATIBLE WITH MULTIPLE TOILET BOWLS

Available in round and elongated styles and fits bowl heights ranging from 14" to 21".

INCREASED STABILITY

The unit attaches directly to the bowl and allows you to move 7½” forward, which positions your shoulders over your feet for optimal balance and positioning. Additionally, arms remain at an ideal positioning angle, which keeps elbows slightly bent to maximize ideal strength in order to exit the seat.

FITS A VARIETY OF USERS

Accommodates individuals ranging in height from 5'2" to 6'4" and supports up to 325 pounds.

EASY CLEANING

Assembly is protected by a plastic shield, which can easily be removed for cleaning.


EASY TRANSFERS

The low angle of the unit allows for easier lateral transfers from mobility devices, transport chairs, etc. In the down position, the arms are lower than the seat for slide board transfers.

COMPANION CONTROL

For user and caregiver convenience, the TILT features a hand-held, push button control to operate the lifting process.

TILT® Toilet Incline Lift
Battery Powered TILT® Toilet Incline Lift
Motor
Cycle Time
Weight Capacity
Dimensions
Weight
Electrical
Actuator Mounting
Frame Material / Finish
Warranty
120 VAC 60Hz
Approx. 15-20 seconds to lift/lower
325 lbs
24” W x 18” H x 24” D (Approx.)
34 lbs
10' Power Cord
Left or Right Side Mounting
Powder Coated Steel
2-year
120 VDC
Approx. 15-20 seconds to lift/lower
325 lbs
24” W x 18” H x 24” D (Approx.)
37.5 lbs
3' 4" Power Cord | 6' 5" Charging Cord
Left or Right Side Mounting
Powder Coated Steel
2-year | 1 year on Battery

NOTE: Weights and dimensions are approximate and subject to change.

For additional specs and dimensions see “Documents"

Available Options

Battery or Corded Power Supply

Although it's our intent to keep all documents current, some documents are subject to change and may take time to update. If you are unsure whether you have the most current revision or if your product is different, contact our technical support.
How do I clean the unit?

The plastic shield can easily be removed and cleaned. Refer to the TILT instructions for specific cleaning guidelines.

Can the corded power unit be converted into a battery powered unit?

No, the corded power unit cannot be converted to a battery powered unit and vice versa.

Can this be placed over a bedside commode?

No, it needs to be bolted to a toilet bowl for maximum stability.

Do you have to wait until it is fully extended to sit on it?

No, you can sit on it at any point in its upward or downward movement.
